The Raven Elite line of high quality rifles is designed for operators who are looking for exceptional quality and performance. Equipped with many innovative features such as ETCS, Quick Spring Change, Sport Trigger as well as Neodymium High Torque motor makes this series the preferred choice for operators of all levels.
The LEVIN PRO GEARBOX, like the name suggests, provides the operator with lightning speed trigger response and high speed cycling. This gearbox is equipped with Raven Evolution's latest E.T.C.S. (Electronic Trigger Control System) which has burst fire programming capability, trigger sensitivity adjustment and binary trigger settings. The precise cycling of the gearbox is controlled by optical sensors to avoid skipping and ensure consistent power delivery to each shot.
Raven Evolution's design team understands the weight of the equipment can greatly effect the efficiency of the operator, therefore their RAVEN ELITE line of products has incorporated the featherlight structure which reduces the overall weight of our rifles while maintaining structural integrity. The venting port at the rear section of the body provides additional airflow to the gearbox and aids heat dissipation.
| EXTERNALS | |
| Grip | Polymer Pistol Grip |
| Mag Catch | Ambidextrous |
| Receiver/Body | CNC Skeletonized Aluminium Alloy Body |
| Selector | Ambidextrous |
| Stock | Polymer Triangle Style |
| INTERNALS | |
| Battery | 11.1V Lipo (Graphene Not Recommended) |
| Bushing/Bearings | 8mm Bearings |
| Gear Set | Harden Steel 13:1 Gearset |
| Gearbox | Full Metal with True Quick Spring Change, Standard V2 Compatible |
| Hop-Up Chamber | Polymer Rotary |
| Inner Barrel Diameter | 6.03mm |
| Motor | Neodymium Magnet High Torque Motor |
| Other | Double Seal CNC Aluminium Loading Nozzle |
| Quick Spring Change | Yes. True Quick Spring Change |
| Trigger System | Electronic Trigger Control System E.T.C.S. |
| Brand | Raven Evolution |
|---|---|
| Recommended Battery | 11.1v Lipo stick Deans |
| Out Of Box FPS | Approx 320fps with 0.20g BBs |
| Mag Type | M4 |
